Mercedes Front Differential Fluid Change Instructions

Est. Time: 45 min - 2 hr
Difficulty: Intermediate
This tutorial provides instructions on how to change the front differential fluid on Mercedes-Benz 4Matic vehicles.

Changing Mercedes's front differential fluid is relatively easy, and most DIYers will be able to complete this job in less than two hours.

What you will need


  1. Drive your Mercedes-Benz up on car ramps. Set the parking brakes. Place wheel chocks behind the rear wheels to prevent the car from rolling back.
  2. Secure the vehicle with jack standsmercedes front differential fluid change diy guide
  3. Slide under the vehicle. Remove the front splash shield. It is held in place with several 8mm screws.MERCEDES front differential ml gl r g s e class
  4. Locate the drain and fill the plug. Note that some models only have a fill plug. The same plug is used for draining the oil. If your Mercedes differential only has one plug, use a transfer pump to suck the oil out of the front differential.mercedes front differential drain and fill plug
  5. Always remove the fill plug first. You need to remove the fill plug first to make sure you can get it off. You don't want to drain the fluid and realize you can't get off the fill plug. remove fill plug mercedes differential
  6. Next, remove the drain plug and allow the oil to drain. Pay attention to the color of the oil. If the oil has a silver look, it may indicate that the bearings of the front differential are failing and will need to be replaced soon.mercedes drain differential fluid
  7. Once all fluid has drained from the front differential of your Mercedes-Benz, it is time to reinstall the drain plug. Replace the plug or the washer if a new drain plug is available.mercedes front carrier fluid change diy draining
  8. Add Mercedes differential fluid until the differential is full and you see fluid starting to drip from the fill hole.mercedes differential oil change
  9. Reinstall the fill hole plug. Re-insert the filler plug at a torque of 30 ft/lb. Make sure you install a new copper washer.
  10. Lower your Mercedes-Benz and take it for a spin.

The pictures in this guide are taken from a differential fitted on 2006-2011 R Class W251, ML-Class W164, and GL Class vehicles. While the front differential is slightly different in E, C, S-Class models, these instructions can be used as a general guide for all owners of Mercedes-Benz with 4Matic.
