Chassis

  • Type: P221

Engine 4.2L 6-Cylinder

  • Recommended oil viscosity: 5W-20

  • Oil certification: API

  • Drain plug torque: 17 ft-lbs

  • Oil capacity: 6.0 quarts

Spark Plug Gap

  • 4.2L 6-Cylinder : 0.044''

Engine 5.4L 8-Cylinder SOHC

  • Recommended oil viscosity: 5W-20

  • Oil certification: API

  • Drain plug torque: 17 ft-lbs

  • Oil capacity: 7.0 quarts

Spark Plug Gap

  • 5.4L 8-Cylinder: 0.044''

Engine 6.2L 8-Cylinder SOHC

  • Recommended oil viscosity: 5W-20

  • Oil certification: API

  • Drain plug torque: 17 ft-lbs

  • Oil capacity: 7.0 quarts

Spark Plug Gap

  • 6.2L 8-Cylinder: 0.044''

Brake fluid and (clutch fluid–if equipped)

  • Type: Motorcraft High Performance DOT 3 Motor Vehicle Brake  Fluid/ PM-1-C / WSS-M6C62-A

  • Capacity: Between MIN/MAX on brake fluid reservoir and to the line or step on clutch fluid reservoir

Coolant

  • Type: Motorcraft Premium Gold Engine Coolant with bittering agent (yellow-colored)

  • Capacity:

    • 4.2L engine coolant: 17.6 quarts (16.7L)

    • 4.6L engine coolant: 20.5 quarts (19.4L)

    • 5.4L engine coolant: 20.9 quarts (19.8L)

Cooling system stop leak pellets

  • Type: Motorcraft Cooling System Stop Leak Pellets/  VC-6 /WSS-M99B37-B6

Front Axle

  • Type: Motorcraft SAE 80W-90 Premium Rear Axle Lubricant/XY-80W-90-QL /WSP-M2C197-A

  • Capacity: 3.5 pints (1.8L)

Rear 8.8/9.75 inch axle fluid

  • Type: Motorcraft SAE75W-140 Rear Synthetic Axle Lubricant/ XY-75W140-QL / WSL-M2C192-A

  • Capacity: 5.5 pints (2.6L)

Rear 10.25-inch axle fluid

  • Type: Motorcraft SAE 75W-140 Rear Synthetic Axle Lubricant/XY-75W140-QL / WSL-M2C192-A

  • Capacity: 6.9 pints (3.3L)

Seat tracks

  • Type: Multi-Purpose Grease/ XG-4 or XL-5 /ESB-M1C93-B

Transmission /steering/parking brake linkages and pivots, brake and clutch pedal shaft/clutch master cylinder push rod to clutch pedal pin (if equipped)

  • Type: Premium Long-Life Grease/XG-1-C / ESA-M1C75-B

Hinges, latches, striker plates, fuel filler door hinge and door check arm

  • Type: Hinges, latches, striker plates, fuel filler door hinge and door check arm/ XG-3-A / ESE-M1C171-A

Power Steering Fluid

  • Type: Motorcraft MERCON V ATF/ XT-5-QM / MERCON V

  • Capacity: Fill to between MIN and MAX lines on reservoir ​​

Transfer case fluid (4X4 / AWD)

  • Type: Motorcraft Transfer Case Fluid/XL–12

  • Capacity: 2.0 quarts (1.9L)

Manual transmission fluid

  • Type: Motorcraft MERCON V ATF/ XT-5-QM / MERCON V

Automatic transmission fluid (4R75E)

  • Type: Motorcraft MERCON V ATF/ XT-5-QM / MERCON V

Windshield washer fluid

  • Type: Motorcraft Premium Windshield Washer Concentrate/ ZC-32-A /\WSB-M8B16-A2

  • Capacity: 4.25 quarts (4.0L)

Fuel

  • Capacity:

  • Reg. Cab 6.5’ box / SuperCab 5.5’ box: 26.0 gallons (98.4L)

  • SuperCrew 5.5’ box : 30.0 gallons (113.6L)

  • SuperCrew 6.5’ box : 27.0 gallons (102.2L)

  •

    Reg. Cab 8’ box / SuperCab 6.5’ box / SuperCab 8’ box : 27.0 gallons (102.2L)

Powertrain


Engine

  • 4.2 L (256 CID) Essex V6

  • 4.6 L (281 CID) Triton V8

  • 5.4 L (330 CID) Triton V8

Transmission

  • 4-speed automatic (4R75E, 4R70E)

  • 5-speed manual

  • 6-speed automatic

Fuel Consumption


FORD 2010 F-SERIES FUEL CONSUMPTION

Safety Ratings


FORD 2019 F SERIES SAFETY RATINGS

References


  1. 2008 Ford F-Series Owners Manual

  2. Ford Ford F-Series- Wikipedia.org

  3. US Department of Energy - FuelEconomy.gov

  4. NHTSA | National Highway Traffic Safety Administration -  NHTSA.gov.

Lights

Front Lights

  • Front Fog Light Bulb: 9140

  • Front Sidemarker Light Bulb: 194

  • Front Turn Signal Light Bulb:

    • 3157-SCK

    • 3157NAK

  • High Beam and Low Beam Headlight Bulb: H13

Rear Lights

  • Back Up Light Bulb:

    • 3156K

    •  912

  • Brake Light Bulb:

    • 3157-SCK

    • 4057K

  • Center High Mount Stop Light Bulb: 921

  • License Plate Light Bulb: 194

  • Parking Light Bulb:

    • 3157-SCK

    • 3157NAK

  • Rear Sidemarker Light Bulb:

    • 3157-SCK

    • 4057K

  • Rear Turn Signal Light Bulb:

    • 3157-SCK

    •  4057K

  • Tail Light Bulb:

    • 3157-SCK

    •  4057K

  • Tailgate Light Bars:vbf-tailgate-light

Interior Lights

  • Dome Light Bulb:

    • 578

    • 6411

  • Luggage Compartment Light Bulb: 921

  • Map Light Bulb:

    • 194

    • 906
