Ford Edge 2015+

In its second generation since 2015, the Ford Edge continued to establish itself as a popular midsize crossover SUV. It featured a more refined and modern design, aligning with Ford's evolving design language. The interior received significant upgrades, with high-quality materials and an intuitive infotainment system. Seating was comfortable and spacious for both front and rear passengers, making it a family-friendly choice.

Regarding performance, the second-generation Edge offered various engine options, including turbocharged and V6 choices, ensuring a balance of power and efficiency. Available all-wheel drive enhanced its versatility and handled well in various road conditions. Safety remained a top priority, with advanced driver-assistance features available, further cementing its appeal in a competitive segment. Overall, the 2015+ Ford Edge was a reliable and well-rounded midsize SUV, appealing to many buyers.

Ford Edge’s specifications, engine oil capacity, spark plug gap, safety rating, fuel consumption, transmission, and light bulb sizes.

Engine 2.0L 4-Cylinder DOHC

• Recommended oil viscosity: 5W-30
• Oil certification: API
• Drain Plug Torque: 20-FT-LBS
• Oil capacity: 5.7 quarts

Spark Plug Gap

• 2.0L 4-Cylinder: 0.032″

Engine 3.5L 6-Cylinder DOHC

• Recommended oil viscosity: 5W-20
• Drain Plug Torque:20 FT-LBS
• Oil capacity: 6.0 quarts

Spark Plug Gap

•  3.5L 4-Cylinder: 0.044″

Engine 2.7L 6-Cylinder DOHC

• Recommended oil viscosity: 5W-20
• Drain Plug Torque: 20 FT-LBS
• Oil capacity: 6.0 quarts

Spark Plug Gap

•  2.7L 4-Cylinder: 0.038″

Fuel

• Capacity
  • Front-Wheel Drive: 18.3 gal (69.3 L)
  • All-wheel drive: 19.2 gallons (72.7L)

Coolant

• Type: Motorcraft Orange Antifreeze/Coolant Prediluted / VC-3DIL-B (US); CVC-3DIL-B (Canada) /WSS-M97B44-D2
• Capacity:
  • 2.0L EcoBoost engine:8.9 quarts (8.4L)
  • 3.5L engines:11.7 quarts (11.1L)

Lock Cylinders

• Type: Motorcraft Penetrating and Lock Lubricant XL-1

Windshield washer fluid

• Type: Motorcraft Premium Windshield Wash Concentrates (the U.S. only) / ZC-32-A (U.S.) CXC-37-(A, B, D, and F) (Canada) /WSB-M8B16-A2/
• Capacity: Fill as required

A/C refrigerant

• Type: Motorcraft R-134, YN-19 (US); CYN-16- R (Canada) / WSH-M17B19-A
• Capacity
  • 2.0L EcoBoost engine: 1.06 lb (0.48kg)
  • 3.5L engines:1.27 lb (0.58kg)

Automatic Transmission Fluid

• Type: Motorcraft MERCON V 7 ATF XT-5-QM / MERCON V
• Capacity:
  • 6F450 :11.0 quarts: (10.4L)
  • 6F35:9.0 quarts (8.5L)

Rear Differential Fluid (All Wheel Drive)

• Type: Motorcraft SAE 80W-90 Premium Rear Axle Lubricant XY-80W90-QL /WSP-M2C197-A
• Capacity: 2.4 pints (1.15L)

A/C refrigerant compressor oil

• Type: Motorcraft PAG Refrigerant Compressor Oil / YN-12-D /WSH-M1C231-B
• Capacity:4.0 oz (118.3ml)

Rear Axle

• Type: Motorcraft SAE 80W-90 Premium Rear Axle 5 Lubricant XY-80W90-QLWSP-M2C197-A
• Capacity: 2.96 pints (1.4L)

Brake Fluid

• Type: Motorcraft High-Performance DOT 4 LV Motor Vehicle Brake Fluid PM-20 / WSS-M6C65-A2
• Capacity: Between MIN and MAX on the reservoir

Door Weatherstrips

• Type: Silicone Lubricant / XL-6 / ESR-M13P4-A

Power Steering Fluid

• Type: Motorcraft MERCON XT-10-QLV / MERCON LV ATF
• Capacity: Between MIN and MAX on reservoir

Power Transfer Unit fluid (All-Wheel Drive)

• Type: Motorcraft SAE 75W-140 Synthetic Rear Axle Lubricant XY-75W140-QL /WSL-M2C192-A
• Capacity: 12 ounces (0.35L)

Hinges, latches, striker plates and rotors, seat tracks, fuel filler door hinges, and springs

• Type: Multi-Purpose Grease (Lithium grease) Motorcraft XL-5 (aerosol)  / CRCSL3151ESB / ESB-M1C93-B

Powertrain

Engine

• Gasoline:
  • 2.0 L EcoBoost I4 turbo
  • 2.7 L EcoBoost V6 turbo
  • 3.5 L Duratec V6
• Diesel:
  • 2.0 L Duratorq I4 (2016–2018)
  • 2.0 L EcoBlue I4 (2018–present)

Transmission

• 6-speed 6F automatic
• 6-speed manual (Europe only, diesel)
• 6-speed PowerShift dual-clutch transmission
• 7-speed automatic
• 8-speed automatic

Fuel Consumption

Interior Lights

• Headlight Bulb High Beam and Low Beam: D3S
• Headlight Bulb Low Beam: H11
• Headlight Bulb High Beam:
  • Halogen Headlights: 9005
  • HID Headlights: H15
• Turn Signal Light Bulb Front: 7440A
• Parking Light Bulb: LED
• Daytime Running Light Bulb: H15
• Side Marker Light Bulb Front: LED

Rear Lights

• Center High Mount Stop Light Bulb: LED
• Brake Light Bulb: LED
• License Plate Light Bulb:
  • 168
  • 917
• Parking Light Bulb: LED
• Tail Light Bulb: LED
• Turn Signal Light Bulb Rear: LED
• Back-Up Reverse Light Bulb: LED
• Side Marker Light Bulb Rear: LED

Interior Lights

• Trunk or Cargo Area Light: LED
• Dome Light Bulb: LED
• Map Light Bulb: LED
