Ford Transit Connect 2021-Present

In its latest iteration from 2021 to the present, the Ford Transit Connect maintains its reputation as a versatile and efficient urban workhorse. Available in cargo van and passenger wagon configurations, this generation offers improved technology and safety features to meet the demands of modern businesses and transportation needs. With its compact size and agile maneuverability, the Transit Connect navigates city streets, making it an excellent choice for urban delivery, small businesses, and shuttle services.

The latest Transit Connect features updated connectivity options, including advanced infotainment systems and connectivity for fleet management, enhancing productivity and efficiency. Its versatile interior design provides adaptable cargo and seating arrangements, ensuring it remains a practical choice for various applications. With its focus on fuel efficiency, low operating costs, and enhanced safety features, the Ford Transit Connect is a reliable and adaptable solution for businesses and fleet operators in urban environments.

Ford Transit Connect specification, engine oil capacity, spark plug gap, safety rating, fuel consumption, transmission, and light bulb sizes.

Engine 2.0L 4-Cylinder DOHC

• Recommended oil viscosity: 5W-20
• Oil certification: API-SN
• Oil capacity: 4.8 quarts

Spark Plug Gap

• 2.0L 4-Cylinder: 0.036”

Engine 2.5L 4-Cylinder DOHC

• Recommended oil viscosity: 5W-20
• Oil certification: API-SN
• Oil capacity: 5.7 quarts

Spark Plug Gap

• 2.5L 4-Cylinder: 0.052”

Engine 1.5L 4-Cylinder

• Recommended oil viscosity: 5W-30
• Oil certification: API

Refrigerant

• Type: WSS-M17B21-A
  • R-1234yf Refrigerant YN-33-A (U.S.)
  • R-1234yf Refrigerant / Frigorigène R-1234yf HS7Z-19B519-BA (Canada)

• Capacity:
• 1.5L DURATORQ-TDCI DIESEL: 28.2 oz (0.8 kg)
•  2.0L DURATEC-HE (MI4)/2.0L FLEX FUEL: 29.1 oz (0.825 kg)

Refrigerant Oil

• Type:
  •  WSS-M2C300-A2
    • Motorcraft® R-1234yf Refrigerant PAG Oil (U.S.)
    • Motorcraft® R-1234yf Refrigerant PAG Oil / Huile PAG pour frigorigène R-1234yf Motorcraft® (Canada)
• Capacity:
  • 1.5L DURATORQ-TDCI DIESEL: 6.8 fl oz (200 ml)
  • 2.0L DURATEC-HE (MI4)/2.0L FLEX FUEL: 5.9 fl oz (175 ml)

Fuel Tank

• Capacity:
  • 1.5L DURATORQ-TDCI DIESEL: 14.5 gal (55 L)
  • 2.0L DURATEC-HE (MI4)/2.0L FLEX FUEL: 15.8 gal (59.8 L)

Diesel Exhaust Fluid

• Type:
  • Motorcraft® Diesel Exhaust Fluid PM-27-GAL, PM-27-JUG (U.S.)
  • Motorcraft® Diesel Exhaust Fluid / Fluide pour échappement diesel Motorcraft® CPM-27-J (Canada)
• Capacity:
  • 1.5L DURATORQ-TDCI DIESEL:4.6 gal (17.6 L)
  • 2.0L DURATEC-HE (MI4)/2.0L FLEX FUEL:

Washer Reservoir

• Type:
  • Motorcraft® Premium Windshield Wash Concentrate with Bitterant ZC-32-B2 (U.S.)
  • Motorcraft® Premium Quality Windshield Washer Fluid / Liquide lave-glace de Haute qualité Motorcraft® CXC-37-A/B/D/F (Canada)
• Capacity:
  • 1.5L DURATORQ-TDCI DIESEL: 3.1 qt (2.9 L)
  • 2.0L DURATEC-HE (MI4)/2.0L FLEX FUEL:3.1 qt (2.9 L)

Brake System

• Type:
  • Motorcraft® DOT 4 LV High-Performance Motor Vehicle Brake Fluid (U.S.)
  • Motorcraft® DOT 4 LV High-Performance Motor Vehicle Brake Fluid / Liquide de Frein automobile Haute performance DOT 4 LV Motorcraft® (PM-20 (U.S. & Canada).

Automatic Transmission

• Type: ​​​​​​​
  • Motorcraft® MERCON® ULV Automatic Transmission Fluid (U.S.)
  • Motorcraft® MERCON® ULV Automatic Transmission Fluid / MERCON® ULV huile pour boîtes automatique Motorcraft® XT-12-QULV (U.S. & Canada)
• Capacity:
  • 1.5L DURATORQ-TDCI DIESEL: 9.0 qt (8.5 L)
  • 2.0L DURATEC-HE (MI4)/2.0L FLEX FUEL: 9.0 qt (8.5 L)

Locks

• Type: ​​​​​​​​​​​​​​
  • Motorcraft® Penetrating and Lock Lubricant XL-1 (U.S.)
  • Motorcraft® Penetrating Fluid / Liquide dégrippant Motorcraft® CXC-51-A (Canada)

Grease

• Type: ​​​​​​​​​​​​​​​​​​​​​
  • Motorcraft® Multi-Purpose Grease Spray (U.S.)
  • Motorcraft® Multi-Purpose Grease Spray / Graisse tout usage en aérosol Motorcraft® (Canada) XL-5-A (U.S. & Canada) ​​​​​​​

Powertrain

Engine

• 1.5 L EA211-evo series T SI BlueMotion (petrol)
• 2.0 L EA288-evo series TDI CR (diesel)

Transmission

• 6-speed automatic 6F-35
• 6-speed manual B6
• 5-speed manual iB5
• 8-speed automatic 8F35 (2019-present)

Safety Rating
