Ford Escape 2001-2007

The Ford Escape, introduced in 2001, marked the automaker's entry into the compact SUV segment. This first-generation model was designed to offer a more car-like driving experience than traditional SUVs, making it well-suited for urban and suburban driving. It featured a boxy but practical exterior design, with a spacious and versatile interior capable of accommodating five passengers and their cargo comfortably.

In terms of off-road capability, the Escape offered an all-wheel-drive system, providing some light off-road capability and added traction in adverse conditions. While the early models came with four-cylinder engines, they provided sufficient power for everyday driving. The first-generation Ford Escape laid the foundation for Ford's success in the compact SUV market, and its practicality, combined with a comfortable ride, made it a popular choice for families and commuters during its initial years.

Ford Escape specification, engine oil capacity, spark plug gap, safety rating, fuel consumption, transmission, and light bulb sizes.

Engine 2.3L 4-Cylinder DOHC

• Recommended oil viscosity: 5W-20
• Oil certification: API
• Drain Plug Torque:20 FT-LBS
• Oil capacity: 4.5 quarts

Spark Plug Gap

• 2.3L 4-Cylinder: 0.052’’

Engine 3.0L 6-Cylinder DOHC

• Recommended oil viscosity: 5W-20
• Oil certification: API
• Drain Plug Torque:19FT-LBS
• Oil capacity: 6.0 quarts

Spark Plug Gap

•  2.0L 4-Cylinder: 0.054’’

Fuel

• Capacity: 16.5 gal (62.5 L)

Coolant

• Type: Motorcraft Premium Gold Engine Coolant with a bittering agent  (yellow-colored) VC-7-B /WSS-M97B51-A1
• Capacity:
  • 2.3L engine (manual transaxle) :5.3 quarts (5.0L)
  • 2.3L engine (automatic transaxle) : 6.3 quarts (6.0L)\
  • 3.0L engine : 10.6 quarts (10.0L)

Lock Cylinders

• Type: Motorcraft Penetrating and Lock Lubricant XL-1

Windshield washer fluid

• Type: Motorcraft Premium Windshield Wash Concentrates (the U.S. only) / ZC-32-A (U.S.) CXC-37-(A, B, D, and F) (Canada) /WSB-M8B16-A2/
• Capacity: 1.2 gal (4.5 L)

A/C refrigerant

• Type: R-1234yf Refrigerant (U.S.) WSS-M17B21-A
• Capacity :1.65 lb (0.75 kg)

Automatic Transmission Fluid

• Type: Motorcraft MERCON V 7 ATF XT-5-QM / MERCON V
• Capacity: 10.2 quarts  (9.6L).

Manual transmission fluid (2wd)

• Type: Motorcraft SAE 75W-90  Gear Oil  XY-75W90-QGL /  WSS-M2C203-A1 and  GL-4
• Capacity: 2.4 quarts (2.3L)

Manual transmission fluid (4X4)

• Type: Motorcraft SAE 75W-90  Gear Oil XY-75W90-QGL / WSS-M2C203-A1 and GL-4
• Capacity: 8 2.5 quarts (2.4L

A/C refrigerant compressor oil

• Type: Motorcraft® R-1234yf Refrigerant PAG Oil (U.S.) /WSS-M2C300-A2
• Capacity:4.1 fl oz (120 ml)

Rear Axle

• Type: Motorcraft SAE 80W-90 Premium Rear Axle 5 Lubricant XY-80W90-QLWSP-M2C197-A
• Capacity: 2.96 pints (1.4L)

Brake Fluid and (clutch fluid, if equipped)

• Type: Motorcraft High-Performance DOT 3 Motor Vehicle Brake Fluid/PM-1-C / WSS-M6C62-A
• Capacity: Fill to the line on the reservoir

Door Weatherstrips

• Type: Silicone Lubricant / XL-6 / ESR-M13P4-A

Power Steering Fluid

• Type: Motorcraft MERCON ATF XT-2-QDX / MERCON

Power Transfer Unit fluid (4X4-Manual Transaxle)

• Type: Motorcraft SAE 80W-90Premium Rear Axle Lubricant XY-80W90-QL WSP-M2C197-A
• Capacity : 12 ounces (0.35L)

Power Transfer Unit fluid (4X4-Automatic Transaxle)

• Type: Motorcraft SAE 75W-140 Synthetic Rear Axle Lubricant Y-75W140-QL /WSL-M2C192-A.
• Capacity : 12 ounces (0.35L)

Body hinges, latches, door striker plates and rollers, seat tracks, fuel filler door hinge and spring, primary and auxiliary hood latches

• Type: Multi-Purpose Grease XG-4 or XL-5 / ESB-M1C93-B

Cooling System Stop Leak Pellets

• Type: Motorcraft Cooling System Stop Leak Pellets VC-6 / WSS-M99B37-B6

Powertrain

Engine

• 2.0 L Zetec I4
• 2.3 L Duratec 23 I4
• 3.0 L Duratec 30 V6

Transmission

• 5-speed G5M manual
• 4-speed CD4E automatic
• 4-speed GF4AX-EL automatic
• Hybrid: planetary gear

Fuel Consumption

Front Lights

• Front Fog Light Bulb: 5202
• Front Sidemarker Light Bulb:
  • 3157-SCK
  • 3157AK
• Front Turn Signal Light Bulb:
  • 3157-SCK
  • 3157AK
• High Beam Headlight Bulb: H7-55W
• Low Beam Headlight Bulb: H11-55W

Rear Lights

• Back Up Light Bulb: 3156K
• Brake Light Bulb:
  •  3157-SCK
  •  4157K
• Center High Mount Stop Light Bulb: 2825
• License Plate Light Bulb: 2825
• Parking Light Bulb:
  • 3157-SCK
  •  3157AK
• Rear Turn Signal Light Bulb: 3156K
• Tail Light Bulb:
  • 3157-SCK
  • 4157K

Interior Lights

• Courtesy Light Bulb: 168
• Dome Light Bulb: 578
• Glove Box Light Bulb: 161
• Luggage Compartment Light Bulb: 5008
• Map Light Bulb: 578
• Vanity Mirror Light Bulb: 6614F
