Mazda Mazda 6 2003-2008

The Mazda 6, produced from 2003 to 2008, marked a significant step forward in the midsize sedan segment. Known for its stylish design, sporty handling, and well-crafted interior, it gained popularity among consumers seeking a more engaging driving experience. Its sharp, distinctive exterior styling, characterized by a prominent grille and flowing lines, set it apart from competitors in its class.

Inside the cabin, the Mazda 6 featured a well-thought-out layout with quality materials and user-friendly controls. It offered comfortable seating and ample legroom for both front and rear passengers. On the road, the Mazda 6 delivered a dynamic driving experience, thanks to its precise steering and balanced suspension. This combination of style, comfort, and performance made the Mazda 6 a competitive choice in the midsize sedan segment during its production years.

Mazda 6 specifications, engine oil capacity, spark plug gap, safety rating, fuel consumption, transmission, and light bulb sizes.

Engine 2.3L 4-Cylinder DOHC

• Recommended oil viscosity: 5W-20
• Oil certification: API
• Drain Plug Torque: 22-30FT-LBS
• Oil capacity: 4.5 quarts

Spark Plug Gap

• 2.3L 4-Cylinder: 0.052”

Engine 2.0L 4-Cylinder DOHC

• Recommended oil viscosity: 5W-20
• Oil certification: API
• Drain Plug Torque: 22-30 FT-LBS
• Oil capacity: 4.4 quarts

Spark Plug Gap

• 2.0L 4-Cylinder: 0.052”

Fuel

• Capacity:
  • U.S.A. and Canada
    • 2WD: 50.0 L (13.2 US gal, 11.0 Imp gal)
    • AWD: 48.0 L (12.7 US gal, 10.6 Imp gal)
  • Mexico: 51.0 L (13.5 US gal, 11.2 Imp gal)

Coolant

• Type: FL-22 type
• Capacity: 7.5 L (7.9 US qt, 6.6 Imp qt)

Manual transaxle oil

• Type:
  • API Service: GL-4
  • SAE: 75W-80
• Capacity: 2.77 L (2.93 US qt, 2.44 Imp qt)

Automatic transaxle fluid

• Type: Mazda Genuine ATF M-V
• Capacity: 8.14 L (8.60 US qt, 7.16 Imp qt)

Brake/Clutch fluid

• Type: SAE J1703 or FMVSS116 DOT-3

Power steering fluid

• Type: Mazda Genuine ATF M-III or equivalent (e.g., Dexron® II)

Powertrain

Engine

• Gasoline:
  • 1.8 L MZR L8 I4
  • 2.0 L MZR LF I4
  • 2.3 L MZR L3 I4
  • 2.3 L MZR L3-VDT DISI turbo I4 (Mazdaspeed 6)
  • 3.0 L Duratec 30 V6
• Diesel:
  • 2.0 L MZR-CD I4

Transmission

• 4-speed 4F27E automatic
• 5-speed JF506E automatic
• 5-speed FS5A-EL automatic
• 5-speed G35M-R manual (I4)
• 5-speed A65M-R manual (V6)
• 6-speed A26MX-R manual (Mazdaspeed 6)
• 6-speed AWTF-80 SC automatic
• 6-speed G66M-R manual

Fuel Consumption

Front Lights

• Fog Light Bulb Front: H11 LED
• Headlight Bulb High Beam: H1
• Headlight Bulb Low Beam(with halogen headlights): H1
• Headlight Bulb Low Beam(with HID headlights): D2S
• Turn Signal Light Bulb Front: 2357A
• Side Marker Light Bulb Front: 2825
• Parking Light Bulb(Compare to original – Option 1): 2825
• Parking Light Bulb(Compare to original – Option 2): 2357A

Rear Lights

• Brake Light Bulb: 7443R
• License Plate Light Bulb: 2825
• Tail Light Bulb: 7443R
• Turn Signal Light Bulb Rear: 7440A
• Back-Up Reverse Light Bulb: 921
• Center High Mount Stop Light Bulb(Compare to original – Option 2) : 7440
• Center High Mount Stop Light Bulb(Compare to original – Option 1): 921

Interior Lights

• Dome Light Bulb: 2825
• Map Light Bulb: 2825
• Courtesy Light Bulb: 2825
