Toyota Camry 2002-2006

From 2002 to 2006, the Toyota Camry represented a continuation of the model's strong reputation for reliability, practicality, and comfort. This generation of the Camry featured a more spacious and refined design, offering a comfortable and roomy interior emphasizing passenger comfort. It boasted user-friendly controls and a well-thought-out layout, showcasing Toyota's dedication to ease of use. The Camry's larger dimensions allowed for generous rear-seat legroom and ample cargo space, making it a practical choice for families and commuters.

In terms of technology, the Camry from this era incorporated modern amenities, including available touchscreen infotainment systems, optional navigation, and features like automatic climate control. Safety features included standard airbags for front and rear passengers and advanced options like antilock brakes and traction control. While the Camry prioritized comfort and reliability over sportiness, it provided a smooth and composed ride, complemented by efficient powertrains.

Toyota Camry specification, engine oil capacity, spark plug gap, safety rating, fuel consumption, transmission, and light bulb sizes.

Chassis

• Type: XV30

Engine 2.4L 4-Cylinder DOHC

• Recommended Oil viscosity: 0W-20
• Recommended Engine Oil: API
• Oil capacity: 4.8 qt

Spark Plug Gap

• 2.4L 4-Cylinder: 0.031”

Engine 3.0L 6-Cylinder DOHC

• Recommended Oil viscosity: 0W-20
• Recommended Engine Oil: SN/RC
• Oil capacity: 5.7 qt

Spark Plug Gap

• 3.0L 6-Cylinder: 0.032”

Fuel

• Capacity: 70L. (18.5 gal, 15.4 Imp. gal.)

Lubrication system

• Capacity:  6.6 qt. (6.2 L, 5.5 Imp. qt.)

Cooling System

• Type: TOYOTA Long Life Coolant” or equivalent, With ethylene−glycol type coolant for proper corrosion protection of aluminum components
  • Do not use alcohol-type antifreeze or plain water alone
• Capacity:
  • 5S−FE engine: 6.9 qt. (7.3 L, 6.1 Imp. qt.)
  • 1MZ−FE engine: 6.8 qt. (9.3 L, 7.7 Imp. qt.)

Clutch

• Type: SAE J1703 or FMVSS No.116 DOT 3

Manual Transaxle

• Type: Gear oil API GL−4 or GL−5 SAE 75W−90
• Capacity:
  • Part-time 4WD models: 1.6 qt. (1.55 L, 1.4 Imp. qt.)
  • Full-time 4WD models: 1.5 qt. (1.40 L, 1.2 Imp. qt.)

Automatic Transaxle

• Type: Automatic transmission fluid D−ll or DEXRON III (DEXRON II)
• Capacity:
  • 1MZ−FE engine: 4.75 qt. (5.0 L, 4.2 Imp. qt.)
  • 5S−FE engine:2.5 qt. (2.6L, 2.2 Imp. qt.)

Steering

• Type: Automatic transmission fluid D−ll or DEXRON III (DEXRON II

Brakes

• Type: SAE J1703 or FMVSS No.116 DOT 3

Powertrain

Engine

• 2.0 L 1AZ-FE I4 (gasoline)
• 2.4 L 2AZ-FE I4 (gasoline)
• 3.0 L 1MZ-FE V6 (gasoline)

Transmission

• 5-speed S51 manual
• 4-speed A140E automatic
• 4-speed A541E automatic

Fuel Consumption

Front Lights

• Fog Light Bulb: 9006
• Headlight Bulb High Beam: 9005
• Headlight Bulb Low Beam: 9006
• Turn Signal Light Bulb: 3457
• Parking Light Bulb: 3457
• Daytime Running Light: 9006
• Side Marker Light Bulb: 168

Rear Lights

• Center High Mount Stop Light Bulb: 921
• Brake Light Bulb: 3057R
• License Plate Light Bulb: 2825
• Tail Light Bulb: 3057R
• Side Marker Light Bulb: 194
• Back-Up/Reverse Light Bulb: 921

Interior Lights

• Glove Box Light Bulb: 2721
• Map Light Bulb: 168
• Trunk or Cargo Area Light:
  • 168
  • DE3021
• Dome Light Bulb:
  • 578
  • DE3175
• Ash Tray Light Bulb:
  • 2721
  • 74
