2017+ Nissan Rogue Sport Rear Brake Pad & Rotor DIY
Worn brake pads announce themselves with squealing or grinding, longer stopping distances, a brake pedal that sits lower than it used to and often a wear warning light on the dashboard. What they do not cause is a soft or spongy pedal. If your pedal feels springy, travels further than it should or sinks slowly toward the floor, that is air in the hydraulic system, a fluid leak or a failing master cylinder, and fitting new pads will not fix it. Find that cause before driving the car. If your symptoms are wear related, the procedure below covers the job.
At a Glance
- Fits: 2017 to 2023 Nissan Rogue Sport.
- Signs of wear: squeal, grinding, thin pads, or a vibration from warped rotors.
- A soft or sinking pedal is a hydraulic problem, not worn pads.
- Tools: jack and stands, 14 mm and 17 mm wrenches, piston tool, caliper grease.
- Pump the pedal until firm before driving, then bed in the pads gently.
What you will need
- Nissan Rogue Sport Rear Brake Pads
- Nissan Rogue Sport Rear Rotor
- Floor Jack
- Jack Stands
- Flathead Screwdriver
- Caliper Grease
- Mechanic Metric Toolset
- 14mm Wrench
- 17mm Wrench
- 17mm Socket
Procedure
- Park the vehicle on a flat-level ground surface. Secure the front wheels using wheel chocks so the vehicle does not move in any direction.

- Loosen the lug nuts of the rear wheel by turning them counterclockwise using a lug wrench.
- Jack up the vehicle’s rear and support it with jack stands.
- Remove the lug nuts and carry the wheel of the vehicle.

- Loosen the upper 14mm guide pin bolt and remove the lower 14mm guide pin bolt on the caliper by turning them counterclockwise using a 14mm wrench.


- Pull the caliper up and remove the brake pads from the carrier by prying them out using a flathead screwdriver.

- Push the piston on the caliper by placing the old brake pad and pushing it using a piston pusher tool.

- Pull the caliper from the carrier and set it aside so the brake hose won’t stretch.

- Remove the carrier from the rotor by removing the two 17mm bolts on the backside of the carrier. Turn the bolts counterclockwise using a breaker bar with a 17mm socket to remove them.


- Remove the metal clips attached to the carrier by prying them out using a flat screwdriver.

- Clean the carrier using a wire brush to remove the corrosion. Do not breathe the dust, and wear your mask when cleaning it.
- Line up the new metal clips to the carrier by pushing them into their proper orientation.

- Ensure the other wheels are secured, and the vehicle won’t roll off. Release the parking brake. Remove the rotor from the vehicle by pulling it out. If the rotor doesn’t come off easily, use a hammer to push the rotor out. Spraying penetrating fluid can help as well.


- Wipe the new rotor clean, line it up to the vehicle, and push it in to set it in.

- Place the carrier back in the vehicle and reinstall its 17mm bolts by turning them clockwise using the 17mm wrench.

- Line up the new brake pads into the carrier and press them to set them. Make sure to place them in their proper orientation.


- Wipe the guide pins clean and add a tiny amount of caliper grease to the guide pins.
- Line up the caliper back to the carrier. Then slide the guide pins back to the carrier and caliper.

- Tighten the guide pin bolts by turning them clockwise using a 14mm wrench.


- Reinstall the rear wheel back to the vehicle.
- Remove the jack stands and release the floor jack.
- Torque the lug nuts to the value in your owner’s manual in a star pattern.
- Press the brake pedal several times until it feels firm before you drive, so the pistons move back against the new pads.
