2011-2017 Nissan Quest Door Mirror Replacement DIY

2011-2017 Nissan Quest Door Mirror Replacement DIY

Is the side mirror of your Nissan Quest broken? This guide provides instructions on changing the driver and passenger door-side rearview mirror on a Nissan Quest.

What you will need

Bestseller No. 1
Spieg NI1321280 Passenger Side Mirror Replacement for Nissan Quest 2011-2014 Power Heated Manual...
Spieg NI1321280 Passenger Side Mirror Replacement for Nissan Quest 2011-2014 Power Heated Manual...
Direct replacement mirror compatible with 11-14 Quest ( w/o BSM , w/o Memory ) ( RH ); Replaces OE # 96301-1JA1C # 963011JA1C # 96301 1JA1C and Parts Link # NI1321280
$109.50
  • Nissan Quest Door Mirror
  • Mechanic Tool Set Metric
    • 10mm socket
    • 3/8″ Extension
    • 3/8″ Ratchet
    • Screwdriver

Procedure

  • Park your Nissan Quest and set the parking brakes. Remove the key from the ignition.park nissan quest to change side view mirror
  • Open the hood and disconnect the negative battery terminal.to change mirror on a Nissan Quest disconnect the battery
  • Watch a video on how to disconnect the battery terminal.
  • Remove the plastic cover behind the door release, and you will notice a 10mm bolt. Remove bolt. mamo driver passenger mirror replacement instructions 2011 2012 2013 2014 2015 2016 2017
  • Remove the window switch, which simply pops up. Behind you will notice two 10mm bolts that need to be removed. how to change door mirror on Nissan Quest 2011 2012 2013 2014 2015 2016 2017
  • Pop out the door panel. Once you remove the bolts in steps 3 and 4, the door panel can be popped out. remove Nissan door panel to access the side view mirror
  • Disconnect the cables that connect to the door handle.Nissan Quest door handle release
  • Remove the door panel.

  • Locate bolts that secure your Nissan Quest side view mirror to the door. Peel off the plastic cover to see the bolts.Nissan Quest side view mirror removal replacement and installation
  • Use the access holes to disconnect the mirror wire harness. This will allow you to remove the mirror. unplug Quest side view mirror
  • Install the new door mirror in reverse order.
  • Application

    This guide applies to Nissan Quest model years 2011, 2012, 2013, 2014, 2015, 2016, and 2017.

    We hope you find the 2011-2017 Nissan Quest Door Mirror Replacement DIY guide helpful. Check these troubleshooting and repair guides for more help on your Nissan.
