Fix BMW Broken Coolant Hose

BMW engine radiator hose outlet to the engine block may break or crack while the engine is running, causing coolant loss and the engine to overheat.


The original outlet is made of plastic and is prone to failure. The part is found on many BMW models, including the popular BMW 335i.

What you will need

  • BMW Water Hose Fitting 11537541992
    • Interchangeable parts 11537544638
    • Fit the N54, N53, N52, and N51 3.0-liter motors
  • OEM BMW Engine Coolant
  • Flathead Screwdriver
  • 10mm Socket
  • Ratchet Wrench

The other advantage of the aluminum design over the OEM part is that the aluminum fitting has a larger diameter, which improves the coolant flow.

Procedure

The fitting is mounted with two bolts and has a 1-inch diameter.

The hose connects the coolant thermostat housing hose at the front of the engine.

  1. Park the BMW and allow the engine to cool down. Set the parking brakes.
  2. Pull the hood release under the dashboard on the driver’s side of the vehicle.
  3. Open the hood and locate the coolant fitting near the front of the engine.crack coolant hose on bmw
  4. Remove two 10mm bolts.Removing bolt on coolant hose
  5. Remove the old fitting from the engine block.removing coolant hose fitting The o-ring needs to be removed as well, as it may get stuck inside.removing the o-ring on the fitting
  6. Clean the outlet on the engine block. Remove any remaining pieces from the coolant hose.removing the leftout pieces of the coolant hose
  7. Install the new fitting. Lubricate the seal O ring before installation. Tighten the two 10 mm bolts.Installing new oring and fitting
  8. Slide the coolant hose on the outlet port.Connecting the coolant hose
  9. Tighten the clamp.tightening the clamp holding the hose
  10. Add engine coolant. It is recommended only to use the BMW engine coolant. add bmw engine coolant

Notes

The best solution is to replace the plastic fitting with a metal part that will not leak and crack like the original. See what you will need to list above.

The broken part may come as one piece with the hose when purchased from the dealer. We could not verify if BMW sells only the outlet fitting. This problem can be fixed by replacing the defective outlet, and it is not necessary to replace the coolant hose.

The hose should be replaced if it is leaking or damaged.

Applications

This part is found on N54, N53, N52, and N51 3.0-liter motors.

This guide applies to the following vehicles:

  • N54 3.0L twin-turbo motors in 335i, 335xi, 135i
  • N53 (3.0-liter non-turbo) in 2006 – 2010 325i, 330i, 525i, 525xi, 528i, 528xi, 530i, 530xi
  • N20 (2.0-liter turbo) Z4 2013 and newer
  • N52 X3
  • N55 motors

We hope you find the “Fix BMW Broken Coolant Hose” guide helpful. Check these troubleshooting and repair guides for more help on your BMW.

Author

  • Rushit Hila • ASE Certified

    Rushit Hila, an ASE-certified engineer (G1 Automotive Maintenance and Repair), brings over two decades of hands-on experience in the automotive world to his writing. With a strong educational background, including a Master of Science in Engineering and a Bachelor of Science in Engineering, he has honed his skills and expertise through years of practical work. As a respected authority in the field, Mr. Hila is dedicated to offering insightful and valuable content that resonates with both vehicle owners and mechanics.
