2004-2008 Mazda 3 Fuse Box Diagram & Location Guide
The Mazda 3 has a fuse box that controls various electrical components. The 2004-2008 Mazda 3 models have the fuse box in the engine bay, near the battery. To ensure the proper functioning of the electrical system, it is important to have a clear understanding of the fuse box diagram and the location of each fuse. In this guide, we will provide a detailed diagram of the 2004-2008 Mazda 3 fuse box, including the fuse location and purpose for each fuse. This information is essential for troubleshooting electrical issues, replacing a blown fuse, and performing regular maintenance on your Mazda 3.
The fuses are located in two places.
- The first set of fuses is located in the engine bay.
- The second fuse is above the passenger footwell, right underneath the dash.
Engine bay
The layout of fuses that you will find under the hood of the Mazda 3 Fuse Layout Fuses and ampere rating
| Earlier Models | Latter Models |
| 1 Cooling Fan | 1 FAN |
| 2 EHPAS | 2 P/ST |
| 3 Various circuits | 3 BTN |
| 4 Headlights | 4 HEAD |
| 5 * | 5 <PTC> |
| 6 * | 6 [P.SEAT] <GLOW> |
| 7 ABS | 7 [ABS 1] |
| 8 ABS | 8 [ABS 2] |
| 9 For the protection of various circuits | 9 ENGINE |
| 10 * | 10 * |
| 11 Ignition Switch | 11 IG KEY 1 |
| 12 Starter Clutch | 12 STARTER |
| 13 Ignition Switch | 13 IG KEY 2 |
| 14 * | 14 <GLOW 1> |
| 15 Blower motor (heater) | 15 HEATER |
| 16 * | 16 <GLOW 2> |
| 17 Rear Defroster | 17 DEFOG |
| 18 * | 18 [AUDIO] |
| 19 ABS | 19 [ABS IG] |
| 20 Fog Lights | 20 [FOG] |
| 21 Horn | 21 HORN |
| 22 * | 22 [DRL] |
| 23 H/Clean | 23 <H/CLEAN> |
| 24 Fuel Pump | 24 F/PUMP |
| 25 Power Steering | 25 P/ST IG |
| 26 Air Conditioner | 26 A/C MAG |
| 27 ALT | 27 [TCM] <ALT> |
| 28 * | 28 <GLOW SIG> |
| 29 * | 29 P.OUTLET |
| 30 PCM | 30 ENG +B |
| 31 Interior Lights | 31 ROOM |
| 32 O2 Heater | 32 [ENG BAR 4] |
| 33 O2 Heater | 33 ENG BAR 3 |
| 34 Injector | 34 EGI INJ |
| 35 Air Flow Sensor | 35 ENG BAR 1 |
| 36 EGR Control Valve |
Interior Fuses
It is located inside the car, on the passenger side, under the dash, and above the passenger footwell. Remove the fuse box cover by shifting the two tabs. Twist the tab shown above and pull down on the fuse panel.
Professional Diagnostics Made Easy All Systems. All Makes. No Subscription.
- ✓ Complete Access to All Vehicle Systems
- ✓ Free Lifetime Updates – No Hidden Fees
- ✓ Live Data + Advanced Bi-Directional Controls
✓ US-Based Technical Support
✓ Detailed Diagnostic Guides
✓ 30-Day Money-Back Guarantee
Free Express Shipping • Trusted by 3,500+ DIYers & Mechanics
| Earlier Models | Latter Models |
| 37 Power door locks | 37 [D/LOCK 2] |
| 38 * | 38 STOP LAMP/HORN |
| 39 Headlight high beams (LH) | 39 HEAD HIGH L |
| 40 Headlight high beams (RH) | 40 HEAD HIGH R |
| 41 * | 41 * |
| 42 * | 42 * |
| 43 Lighter | 43 CIGAR |
| 44 Audio System | 44 RADIO |
| 45 Power Mirror | 45 [MIRROR] |
| 46 Tailight (RH), Parking Lights (RH), License Plate Lights | 46 TAIL R |
| 47 For the protection of various circuits (OBD) | 47 OBD |
| 48 * | 48 * |
| 49 TR/Lock | 49 [TR/LOCK] |
| 50 Control Unit | 50 * |
| 51 Turn Signals, Hazards | 51 * |
| 52 Moonroof | 52 [SUN ROOF] |
| 53 Front Washer, Rear window wiper, and washer | 53 WASHER |
| 54 * | 54 * |
| 55 Right Power window | 55 <P/WIND R> |
| 56 Left Power window | 56 <P/WIND L> |
| 57 Alarm | 57 <ALARM> |
| 58 Mirror Defroster | 58 [M/DEF] |
| 59 * | 59 * |
| 60 Headlight Low beams (RH) | 60 HEAD LOW R |
| 61 Headlight Low beams (LH) | 61 HEAD LOW L |
| 62 * | 62 * |
| 63 * | 63 * |
| 64 * | 64 * |
| 65 Supplemental Restraint System | 65 SAS |
| 66 Instrument Cluster, Immobilizer system, Shift Lock system | 66 METER |
| 67 ABS, EHPAS (Ignition) | 67 IGNITION |
| 68 Windshield Wiper | 68 WIPER |
| 69 Engine For the protection of various circuits | 69 ENGINE |
| 70 Auto Wiper | 70 [IG SIG] |
| 71 Supplemental Restraint System | 71 SAS 2 |
| 72 * | 72 * |
| 73 * | 73 * |
| 74 Seat Warmer | 74 [SEAT WARM] |
| 75 Power door locks | 75 [D/LOCK 1] |
| 76 AC | 76 A/C |
| 77 Power Window (LH) | 77 [P/WIND L] |
| 78 Power Windows (RH) | 78 [P/WIND R] |
| 79 Reverse Lights | 79 BACK |
| 80 MoonRoof | 80 [SUN ROOF] |
| 81 Tailights (LH) Parking Lights (LH) | 81 TAIL L |
| 82 Illumination | 82 ILLUMI |
Is the radio, cigarette outlet, or lights not working on your Mazda 3? A common problem could be due to a blown fuse. Learn where to find the fuses on a Mazda 3 car. Is your Mazda 3 not starting? Are you trying to troubleshoot a dashboard warning light? If yes, check out our guide on diagnosing vehicle problems like a mechanic.
