Mazda Outer Tie Rod Replacement

Learn how to change outer tie rods on a Mazda. Replacing the tie rod on a Mazda is simple and can be completed in less than an hour. Once the tie rod is replaced, the vehicle will need a wheel alignment.

Symptoms

• Loose steering
• Noise when hitting bumps (Can also be caused by worn sway bar bushings.)
• Shaking in the steering wheel
• Alignment is off
• The car pulls to the side at highway speed
• Uneven tire wear

What you will need

Bestseller No. 1

Detroit Axle – Front 6pc Tie Rods Kit for 04-13 Mazda 3, 09-13 3 Sport, 06-17 5, 4 Suspension Outer…

Replacement for 2004-2013 Mazda 3 – [2009-2013 Mazda 3 Sport] – 2006-2017 Mazda 5; Kit Includes: (4) Front Inner Outer Tie Rod Ends + (2) Boots

$46.26

• Outer Tie Rod for Mazda
• 15mm socket
• 17mm socket
• 19mm socket
• Ratchet
• Torque Wrench
• Tie Rod Puller
• Floor jack
• Jack stands

Procedure

1. Park the Mazda on a flat surface. Place the shifter in the park, and engage the parking brakes.
2. Before raising the Mazda, break loose the lug nuts.
3. Next, jack up the car at the jacking points using a floor jack. Support the vehicle with jack stands. Never depend on the jack alone.
4. Locate the outer tie rod. Here is a picture of the tie rod on a Mazda 5.
5. Remove the cotter pin from the tie rod end. Use a wrench to loosen up the bolt that secures the tie rod. Next, use a marker or chalk to mark the threads on the inner tie rod.
6. Use a tie rod puller or separator to disconnect the tie rod from the knuckle.https://vimeo.com/233005532
7. Install the new tie rod on your Mazda in reverse order. Torque the nut to 18 ft/lbs.

Do I Need Front Wheel Alignment?

• Once you replace the tie rods, you will need to get the front wheels aligned. You will need to take your car to a wheel alignment shop. If you don’t align your wheels, your car will pull to one side, and the tires may wear out quickly or unevenly.
• On average, you will pay $100 to align the front wheels. You can also align your car at the Mazda dealership for around $120-$145.

Replacement Cost

• The cost to change Mazda tie rods can vary from $200 at independent auto mechanics to $480 at a Mazda dealership. This doesn’t include the cost of alignment.
• The DIY cost to replace Mazda tie rods is under $75, assuming you have a few basic tools. Plus another $80-$120 for the wheel alignment.

Frequently Asked Questions

We hope you find the Mazda Outer Tie Rod Replacement guide helpful. Check these troubleshooting and repair guides for more help on your Mazda.
