Hyundai Elantra Fuses Fuse Location

2011-2016 Hyundai Elantra Fuse List, Location

The main fuses on Hyundai Elantra models from 2001 to 2016 are located in the engine bay and under the dashboard.


Hyundai Elantra (model years: 2011, 2012, 2013, 2014, 2015, 2016) have fuse boxes in two locations.

  • Fuse Box Under the Dashboard, Driver’s Side
  • Fuse Box Engine Bay

What you will need

  • Hyundai Elantra Blade Type Mini Fuses

Interior Instrument panel

hyundai elantra fuses list
Fuse NameFuse ratingProtected Component
START7.5AW/O Smart Key: ICM Relay Box(Burglar Alarm Relay), With Smart Key: A/T – Transaxle Range Switch, M/T – ECM, E/R Fuse & Relay Box(Start 1 Relay), Smart Key Control Module
A/BAG15ASRS Control Module, Passenger Weight Classification Sensor
A/BAG IND7.5AInstrument Cluster
CLUSTER7.5AISG LDC (Audio), Cluster (ISG)
C/LIGHTER15ACigarette Lighter
BCM7.5ASmart Key Control Module, BCM
A/CON SWITCH7.5AA/C Control Module
MODULE 27.5AElectro Chromic Mirror, ESC Off Switch
MDPS10AEPS Control Module
MODULE 47.5ARear Parking Assist Sensor LH/RH (IN/OUT), A/C Control Module(Auto A/C), ATM Lever Indicator
IG120AE/R Fuse & Relay Box(Fuse – TCU 1, B/UP LP, ECU 3, ABS 3)
PDM 37.5ASmart Key Control Module
POWER OUTLET FRT20APower Outlet
MODULE 610AAMP, Power Outside Mirror Switch, Audio, A/V & Navigation Head Unit, Digital Clock
HTD MIRR10ADriver/Passenger Power Outside Mirror, A/C Control Module
MODULE 37.5AAudio, Tire Pressure Monitoring Module, Digital Clock, BCM, Instrument Cluster, Driver/Passenger Seat Warmer Module
BRAKE SWITCH10A
SPARE15A
SUNROOF15ASunroof
SPARE15A
SPARE15A
BLOWER10AManual A/C – A/C Control Module, ECM/PCM, Blower Resistor
INTERIOR LAMP10ALuggage Lamp, Vanity Lamp LH/RH, Room Lamp, Overhead Console Lamp, Ignition Key Ill. & Door Warning Switch(W/O Smart Key)
TRUNK10ATrunk Relay
MODULE 17.5ASport Mode Switch(A/T), Key Solenoid(W/O Smart Key)
SPARE15A
S/HEATER RR15ARear Seat Warmer Switch LH/RH
MODULE 77.5ASmart Key Control Module, BCM
MULTIMEDIA15AAudio, A/V & Navigation Head Unit

Engine Compartment Fuse Panel

fuse box location diagram hyundai elantra
MDPS80AEPS Control Module

B+160ASmartJunction Box(ARISU 1 (4CH), IPS 1, FUSE – P/WDW LH, P/WDW RH, TRUNK, AMP 1)

C/FAN40AC/FAN Lo Relay, C/FAN Hi Relay

ABS 140AESC Module, Multipurpose Check Connector

RR HTD40ARR HTD Relay

BLOWER40ABlower Relay

SPARE40A

B+260ASmart Junction Box(Turn Signal Lamp Sound Relay, ARISU 2 (4CH), IPS (1CH),
IPS (2CH), FUSE – P/SEAT DRV, SUNROOF)

B/UP LAMP10AElectro Chromic Mirror, A/V & Navigation Head Unit, Rear Combination Lamp (In) LH/RH, M/T –
Back-Up Lamp Switch, BCM, Instrument Cluster

TCU 115AM/T – Vehicle Speed Sensor, A/T – Transaxle Range Switch

ABS 310AESC Module, Multipurpose Check Connector

ECU 310AStop Lamp Switch, M/T – ECM, A/T – PCM


WIPER10ARain Sensor, M/T – ECM, A/T – PCM

B+350ASmart Junction Box (Leak Current Autocut Device, FUSE – MODULE 1, PDM 1, PDM 2, DR LOCK)

EMS40AEMS Box(Engine Control Relay, FUSE – ECU 4, A/CON, F/PUMP)
ISG INVERTER50AOil Pump Inverter

STOP LP15AStop Lamp Switch, Smart Key Control Module

S/HEATER FRT20ADriver/Passenger Seat Warmer Module

HORN15AHorn Relay

IG 240AW/O Smart Key: Ignition Switch, Start 1 Relay,
With Smart Key: PDM 4 (IG2) Relay, Start 1 Relay

ABS 230AESC Module, Multipurpose Check Connector

IG 140AW/O Smart Key: Ignition Switch, With Smart Key: PDM 3 (IG1) Relay, PDM 2 (ACC) Relay

F/PUMP15AF/PUMP Relay


ECU 415APCM (A/T), ECM (M/T)

A/CON10AA/C COMP Relay

INJECTOR10AInjector #1 / #2 / #3 / #4, A/C COMP Relay, F/PUMP Relay

ECU 210APCM (A/T), ECM (M/T)

IGN COIL 120AIgnition Coil #1 / #2 / #3 / #4, Condenser

ECU 120A

SENSOR 210AImmobilizer Module, Camshaft Position Sensor #1 / #2
SENSOR 110AOxygen Sensor (UP/DOWN), Canister Close Valve, Variable Intake Solenoid Valve, Oil Control
Valve #1 / #2, Purge Control Solenoid Valve, C/FAN LO Relay, C/FAN HI Relay
hyundai elantra fuse box location
hyundai elantra fuse diagram
hyundai elantra fuses 2011 2012 2013 2014 2015 2016
hyundai elantra fuses 2011 2012 2013 2014 2015 2016

Frequently Asked Questions

Where can I find the fuses of my Hyundai Elantra?

1. Fuse Box on the Driver’s Side of the Engine Bay.
2. Fuse Box below the Driver’s Dashboard.

How to know if I have a blown fuse?

Check the fuse wire and see if there’s a gap in the wire or if there’s a dark mark inside the glass of the fuse.

How much does a fuse replacement cost?

If you’re replacing the fuse, it will cost $10-$20. From the dealership, it will cost around $100.

We hope you find the 2011-2016 Hyundai Elantra Fuse List, and Location guide helpful. Check these troubleshooting and repair guides for more help on your Hyundai.
