Hyundai Wiper Blade Replacement & Size Lookup
Look up windshield wiper sizes for any Hyundai model and learn how to replace the windshield wiper yourself.
This next section provides step-by-step instructions on Changing the Hyundai wiper blade yourself.
Hyundai Windshield Wiper Blade Size
Hyundai | From | To | Driver Wiper (inches) | Passenger Wiper (inches) | |
Accent | 2000 | – | 2005 | 20 | 18 |
Accent | 2005 | – | 2010 | 22 | 16 |
Accent | 2010 | – | 2016 | 22 | 16 |
Elantra | 2006 | – | 2010 | 24 | 18 |
Elantra | 2011 | – | 2016 | 28 | 14 |
Atos | 2099 | – | 20 | 17 | |
Azera | 2006 | – | 24 | 19 | |
Coupe | 2001 | – | 20 | 18 | |
Excel | 2090 | – | 2094 | 18 | 18 |
Getz | 2002 | – | 2008 | 22 | 14 |
Grandeur | 2098 | – | 2002 | 22 | 20 |
i10 | 2008 | – | 22 | 16 | |
i30 | 2009 | – | 24 | 18 | |
Matrix | 2001 | – | 2010 | 22 | 16 |
Santa Fe | 2001 | – | 2006 | 22 | 20 |
Santa Fe | 2007 | – | 2012 | 24 | 18 |
Santa Fe | 2013 | – | 24 | 18 | |
Sonata | 2002 | – | 2005 | 22 | 20 |
Sonata | 2004 | – | 2010 | 24 | 19 |
Sonata | 2009 | – | 2016 | 26 | 18 |
Starex | 2097 | – | 24 | 20 | |
Trajet | 2000 | – | 26 | 22 | |
Tucson | 2005 | – | 24 | 16 |
How to Replace Hyundai Wiper Blades
- Turn off the engine. Make sure the hood is closed.
- Slowly move the wiper arm up. You do this by raising the wiper arm toward you.
- Turn the wiper blade of your Hyundai 90 degrees or perpendicular to the windshield wiper arm. Turning the wiper blade assembly will expose the locking clip. Be careful so that the wiper arm doesn’t fall on your Hyundai windshield, or you risk breaking the windshield.
- Press the locking clip on your Hyundai Elantra / Sonata wiper blade, etc. Once you compress the clip, you can slide the blade assembly downward. Pull down the wiper blade. This will allow you to remove the old, worn-out Hyundai wiper blade.
- Install the new wiper blade in reverse order. Make sure the wiper blade is locked in place. You should hear the locking clip lock in place. Ensure the wiper blade is secure, and slowly lower the wiper blade on the windshield.
We hope you find the Hyundai Wiper Blade Replacement & Size Lookup guide helpful. Check these troubleshooting and repair guides for more help on your Hyundai.
If you have questions, please leave a note in the comments section.
TIPS
- Newer Hyundai models require that you hold the wiper switch pressed forward for 5 seconds to move the wipers into the service position. Once the wipers move into the service position, you can remove the key from the ignition and then replace the wiper. This is common on some newer Hyundai models, such as Sonata.
- If the hood doesn’t allow you to move the wiper blade up, move the wiper arm to the vertical position. On the older Hyundai models and newer ones, such as Elantra and Accent, you can turn on the wipers and turn the ignition off when the wiper is in the up/top position.
- Don’t try to move the windshield wiper blade arms manually. Doing so risks damaging the wiper motor of your Hyundai.
- Always use the correct size wiper blade size. Never use larger or wrong-size wiper blades.
- Replace windshield wiper blades at least once a year or more frequently if needed. The wipers will eventually stop cleaning properly, indicating that they are worn or cracked and require replacement.
