Jump-Start Mitsubishi with Dead Battery

Can’t start your Mitsubishi due to a dead battery? Learn how to fix the problem by jump-starting the dead battery of your Mitsubishi. This guide provides instructions on jump-starting a dead battery on a 2019 Mitsubishi Outlander. The battery in your vehicle could be dead, or the voltage discharged for various reasons.

Whatever the cause, it may leave you on the side of the road or stranded in a parking lot. Keeping a jump starter or jumper cables is essential for roadside emergencies. In this guide, we will show you how to use them.

What you will need

• Jump starter or
• Jumper cables

Procedure

1. Begin by seeing if the key fob will unlock the vehicle’s doors.
2. If the doors will not unlock, there is a release on the back of the fob that allows you to pull the metal key out of the fob. Use the key to unlock the doors.
3. Ensure the battery is the problem, not the key fob; try starting the vehicle and see if it turns over. The battery is likely low if clicking can be heard or the vehicle’s engine tries to turn over but will not start.
4. Pop the hood of the vehicle open with the lever under the dash. Raise the hood and place it on its prop.
5. Use the jump starter to try and start the engine. The terminals can be seen and connected underneath the airbox inlet. This part does not need to be removed.
6. Important safety note: the positive cable is connected first and the negative last. This will avoid any high voltage shock or sparks. The negative cable can be grounded to the vehicle’s body or connected to the negative battery terminal.
7. If using jumper cables, always connect the dead battery first and be careful not to touch the cable leads together as they will also arc.
8. Always ensure all the leads have a good connection to the terminals, give them a wiggle, and ensure they are on bare metal.
9. Charge the battery a few minutes before attempting to start. Waiting will allow the electrical circuit of the car, the battery, and the jump starter in parallel to build a current. This will greatly increase the odds of the jump start to work.
10. Attempt to start the car, and once started, allow the vehicle to charge with the jump-starter or jumper cables still attached for five to ten minutes. This will allow the battery to build enough charge to stay running. If the vehicle dies or does not start, the battery may be too bad to stay running, or the alternator is bad and draining the battery.
11. In both cases, check the battery and the alternator, and run a charging system test with a battery and alternator load tester.
12. Remove the cables in reverse order once the vehicle is sufficiently running and the battery has enough charge. Always remove black, then red (negative, then positive). Get back on the road, to work, or wherever you were headed; you are done!

Your battery may need to be recharged or replaced. Common causes of a discharged or bad battery:

• Leaving the lights on drains the battery
• A parasitic drain from the vehicle’s electrical system
• A bad alternator/generator
• Extreme temperatures
• Battery corrosion or loose cables/ terminals
• The battery is bad due to age

Vehicle Applications

All Mitsubishi models include Galant, Lancer Evo, Outlander, Eclipse, Mirage, and more. All-year models including current-gen: 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, and 2021.
