Fuse List and How to Locate the Fuse Box, Replace Fuses Relays on a 2012-2017 Toyota Camry XV50
Procedure
- Pull the hood release under the dashboard.
- Locate the hood latch on the vehicle’s front and pull the tab up to unlock the hood latch.
- Pull the hood up until the hood struts are in the hold position.
- Locate the fuse box on the driver’s side of the engine compartment.
- Press the clips on the front and back to unlock the fuse box cover.
- Pull the cover out from the vehicle.
- Remove the fuse puller on the cover by pulling it out.
- Remove the fuse using the puller.
- Fuse and relay descriptions and components on the engine compartment.
Fuse Description Ampere Fuse Component METER-IG2 5 A Gauge and Meters FAN 50 Electronic Cooling Fans H-LPCLN 30 No Circuit HTR 50 Air Conditioning System ALT 120 Charging System ABS NO.2 30 Stability Control System ST/AM2 30 Starter System H-LP-MAIN 30 Headlights (Low Beam) ABS NO.1 50 Stability Control System EPS 80 Electronic Power Steering S-HORN 7.5 Horn EFI NO.2 15 Multiport/Sequential Fuel Injection System, Electronic Controlled Transmission System EFI NO.3 7.5 2AR-FE: Multiport/Sequential Fuel Injection System EFI NO.3 10 2GR-FE: Multiport/Sequential Fuel Injection System INJ 7.5 Multiport/Sequential Fuel Injection System ECU-IG2 NO.3 7.5 Multiport/Sequential Fuel Injection System, Steering Lock System, Electronic Transmission IGN 15 Starter System D/L-AM2 20 No Circuit IG2-MAIN 25 IGN, INJ, METER-IG2, ECU-IG2 NO.3, A/Bm ECU-IG2 NO.2, ECU-IG2 NO.1 ALT-S 7.5 Charging System MAYDAY 5 MAYDAY TURN&HAZ 15 Turn Signal Lights, Emergency Flashers, Gauge & Meters STRG LOCK 10 Steering Lock System AMP 15 Audio System H-LP LH-LO 15 Halogen Headlight: Low Beam (LH), Manual Headlight Leveling System H-LP LH-LO 20 Discharge Headlight: Low Beam (LH), Manual Headlight Leveling System H-LP RH-LO 15 Halogen Headlight: Low Beam (RH) H-LP RH-LO 20 Discharge Headlight: Low Beam (RH) MNL H-LP LVL 7.5 Discharge Headlight: Manual Headlight Leveling System EFI-MAIN NO.1 30 Multiport/Sequential Fuel Injection System, EFI NO.2, EFI NO.3, A/F Sensor SMART 5 No Circuit ETCS 10 Electronic Throttle Control System TOWING 20 No Circuit EFI NO.1 7.5 Multiport/Sequential Fuel Injection System, Electronic Controlled System EFI-MAIN NO.2 20 2AR-FE: A/F Sensor A/F 20 2GR-FE: A/F Sensor AM 2 7.5 Smart Key System RADIO-B 20 Audio System, Navigation System DOME 7.5 Clock, Vanity, Interior, Personal, Trunk, Door Courtesy Lights ECU-B NO.1 10 Communication System, Smart Key System, Gauge and Meters, Tire Pressure, - Locate the other fuse box on the driver’s seat footwell near the emergency brake.
- Pull the cover from the top to remove it.
- Fuse and relay descriptions and components on the driver’s seat footwell.
Fuse Description Ampere Fuse Component ECU-IG1 NO.2 10 Seat Heaters, Smart Key System, Shift Lock Control System, Wireless Remote Control, Multiplex Communication System, Audio System, Tire Pressure Warning System, Moon Roof, Auto Anti-Glare Rear View Mirror, Navigation System ECU-IG 1 NO.1 10 Electric Cooling Fans, Steering Sensor, Vehicle Stability System, Multiport/Sequential Multiport Fuel Injection System, Rear Window Defogger, Blind Spot Monitor, Outside Rear View Defoggers, Charging System, Rear View Mirror Defogger. PANEL 10 Air Conditioning System, Glove Box Light, Personal Lights, Switch Illumination, Interior Lights, Navigation System, Audio System TAIL 15 Side Marker Lights, Rear Parking Lights, License Plate Lights, Fog Lights EPS-IG1 7.5 Electric Power Steering DOOR R/R 20 Rear Right Power Windows ECU-IG 1 NO.3 7.5 Blind Spot Mirror DOOR F/L 20 Front Left Power Windows, Outside Mirror Control ECU S/HTR & FAN F/L 10 Seat Heaters DOOR R/L 20 Rear Left Power Windows H-LP LVL 7.5 Automatic Headlight Leveling System WASHER 10 Windshield Wipers and Washer A/C-IG1 7.5 Air Conditioning System WIPER 25 Windshield Wipers and Washer BKUP LP 7.5 Back-up Lights DOOR NO.1 30 Power Windows WIPER-S 5 No Circuit EPS-IG1 7.5 Electric Power Steering P/OUTLET RR 20 Power Outlet SFT LOCK-ACC 5 Shift Lock Control System DOOR R/R 20 Rear Right Power Windows S./HTR&FAN F/R 10 Right Front Seat Heaters DOOR R/L 20 Rear Left Power Windows S/HTR&FAN F/L 10 Left Front Seat Heaters OBD 10 On-Board Diagnostic System ECU-B NO.2 10 Smart Key System, Tire Pressure Warning System DOOR NO.2 20 Power Windows AM1 7.5 Starter System, Multiport/Sequential Multiport Injection System STOP 7.5 Tail Lights, High Mounted Brake Light, Anti-Lock Brake System P/SEAT RR 30 No Circuit A/C -B 7.5 Air Conditioning System S/ROOF 10 Moon Roof P/SEAT FR 30 Power Seats PSB 30 No Circuit D/L-AM1 20 Multiplex Communication System, Trunk Switch, Power Door Lock TI&TE 20 No Circuit A/B 10 Front Passenger Occupant Classification System, SRS Airbag System ECU-IG2 NO.1 7.5 Multiport/Sequential Multiport Injection System ECU-IG2 NO.2 7.5 Blind Spot Monitor, Smart Key System CIG&P/OUTLET 15 Power Outlet ECU-ACC 7.5 Communication System, Audio System, Clock, Navigation System, Side Mirror S/HTR &FAN FI R 10 Seat Heaters S/HTR RR 20 No Circuit DOOR F/R 10 Front Right Power Windows, Outside Mirror Control ECU ECU-IG1 NO.3 7.5 No Circuit
