Mercedes 722.9 Transmission Seal O Ring Leak

Mercedes-Benz cars equipped with a 7-Speed automatic transmission may leak transmission fluid from the O ring fittings. Leaks typically develop when transmission lines connect to the transmission cooler/radiator. The oil leak can develop to the point that all transmission fluid is lost. The first symptoms are transmission fluid leak, Mercedes-Benz going into limp mode, and the transmission getting stuck in one gear.


As more transmission fluid is lost car no longer moves when placed in Drive or Reverse. This problem affects many models from 2005-2015, including E, C, S, ML, GL, ML, G Class, and others with 722.9 transmissions. This is a simple DIY fix. It requires the O rings to be replaced to prevent transmission fluid leaks.

What is needed

Instructions

First, inspect for leaks.

transmission engine leaks

If any transmission fluid leaks are detected, disconnect the line.

disconnecting the transmission hose

Pull out the black cover.

transmission cap removal

You will see a C clip that needs to be removed.

remove c clip from transmission hose

Close up a picture of the clip that needs to be removed.

transmission-seal-removal

The transmission line can be pulled out.

removing transmission line

O Ring can be replaced. Reinsert the transmission line and the C clip. When you disconnect the transmission line, you will lose some transmission oil. To minimize the leak from the disconnected transmission line, either block the hose or keep it as high as possible. Once you are done with changing the O rings, check the transmission fluid level.

We hope you find the Mercedes 722.9 Transmission Seal O Ring Leak guide helpful. Check these troubleshooting and repair guides for more help on your Mercedes-Benz.
