Mercedes Suspension Ride Height Level Sensor

⌂ » Auto Maintenance » General Maintenance

Posted onNov 20, 2019Dec 28, 2022 Updated onDec 28, 2022

Mercedes-Benz vehicles equipped with airmatic suspension have three to four Suspension Height Level Sensors. Input from these sensors is used by the airmatic suspension to automatically self-level the vehicle height based on the vehicle load.

Mercedes-level sensors determine the position of the airmatic strut, which determines the vehicle’s load. Level sensors are also known as suspension ride height sensors. A level sensor should not be confused with the axle damping valve unit.

How to Replace Mercedes-Benz Ride Level Sensor?

In the following video, you will learn how to remove and replace the level sensor on Mercedes-Benz with Airmatic suspension. The work was performed on a W221 S-Class, but the procedure is the same for other models, including Mercedes-Benz E-Class, GL-CLass, ML-Glass, CLS-CLass, R-Class, and other models with airmatic.

What you will need

Bestseller No. 1


NewYall Front & Rear Suspension Height Level Sensor
NewYall Front & Rear Suspension Height Level Sensor

$17.99

  • Mercedes Suspension Level Sensor
  • Torx Socket Set

Many Mercedes-Benz owners experience a problem because the linkage of the level sensor breaks or the level sensor itself fails. When one sensor is faulty, the airmatic system will try to level the vehicle, leading to a too high or too low vehicle.

There is a level sensor for each of the front two air struts. A third-level sensor is often located above the rear axle (near the rear differential) and attached to the rear sway bar. The third suspension level sensors measure the approximate position of the two back air struts. If this level sensor fails or the linkage breaks, the vehicle will drop on the back (both sides).

Symptoms

bad mercedes suspenstion ride height level sensor

If one of the suspension height level sensors fails, you will notice one or more of the following symptoms.

  • Airmatic Malfunction Visit Workshop message on the instrument cluster
  • Stop Car To Low message.
  • The vehicle drops to the ground at one of the front corners.
  • The strut is locked out at full inflation and very high
  • The back of the car (both sides) drops to the ground
    if the rear axle sensor fails. The rear of the car will
    not raise even with new struts.
  • Airmatic – Visit Workshop Displayed in Instrument
    cluster and Fault Code 5151 – [B22/3 (Rear Axle Level
    Sensor): Signal Implausible]

Troubleshooting Mercedes Level Sensor

Mercedes Front Level Sensor

When a Mercedes is taken in for another service, such as a control arm or air strut replacement, the mechanic working on the car accidentally bends the B22/9 or B22/8 sensor mounting plate linkage.

The airmatic control module no longer reads the correct vehicle heights. We recommend you check the level sensor link, wiring, and mounting place. It is more common for the link to bend or fail than the level sensor from our experience. The link itself can often break, causing the level sensor to malfunction.

If you are experiencing problems with the airmatic, always start by checking the ride height level sensor links. Remove the front two wheels and inspect the suspension level sensor mounted next to the upper control arm.

You have level sensors at each front strut. Depending on the chassis, you will have a level sensor above the rear axle or one for each rear strut.

If you notice that the linkage is bent, you can bend the sensor back to the correct position. The problem is that, in many cases, the link is either rusted or damaged beyond repair. If that is the case, we recommend replacing a faulty level sensor with an OEM Mercedes Level Sensor. If the link is not damaged, the next step is to read the fault codes using an OBD-II scanner designed for Mercedes-Benz vehicles.

YOUCANIC UCAN2 SCANNER

The YOUCANIC Full System Scanner can read and clear fault codes through every control module on a vehicle.

Where is Level Sensor Located on a Mercedes-Benz?

Description of Ride Height Level Sensors on vehicles with three sensors. Vehicles with four sensors have one sensor at each air strut.

  • B22/8 Left the front level sensor
  • B22/9 Right front level sensor
  • B22/3 Rear axle level sensor

You can purchase replacement Mercedes-level sensors online. Search for the Mercedes Ride Height Sensor for your model.

We hope you find the Mercedes Suspension Ride Height Level Sensor guide helpful. Check these troubleshooting and repair guides for more help on your Mercedes-Benz.
